TLA-120.2 ROTOR

Maximum speed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120 000 rpm

Density rating at maximum speed. . . . . . . . . . . . . . . . . . . . 1.7 g/mL

Relative Centrifugal Field* at maximum speed

At rmax (38.9 mm) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 627 000 × g

At rav (31.8 mm) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 513 000 × g

At rmin (24.5 mm). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 395 000 × g

k factor at maximum speed . . . . . . . . . . .. . . . . .. . . . . . . . 8

Conditions requiring speed reductions . . . . . . . . . . . . . ...... . see RUN SPEEDS

Number of tube cavities . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Available tubes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . see Table

Nominal tube dimensions (largest tube) . . . . . . . . . . . . . .. . . 11 × 34 mm

Nominal tube capacity (open-top). . . . . . . . . . . . .. . . . . . . . 1.0 mL

Nominal tube capacity (Quick-Seal®). . . . . . . . . . . . .. . . . . . 2.0 mL

Nominal rotor capacity . . . . . . . . . . . . . . . . . .. . . . . . . . . 2.0 mL

Approximate acceleration time to maximum

speed (fully loaded) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 1/2 min

Approximate deceleration time from maximum

speed (fully loaded) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 min

Weight of fully loaded rotor . . . . . . . . . . . . . . . . . . . . .. . . 0.6 kg (1.2 lb)

Rotor material . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . titanium
